CyberPower PR3000ERTXL2U uninterruptible power supply (UPS) Line-Interactive 3 kVA 3000 W 8 AC outlet(s)

Roll over image to zoom inClick to Open expanded view

CyberPower PR3000ERTXL2U uninterruptible power supply (UPS) Line-Interactive 3 kVA 3000 W 8 AC outlet(s)

Name: CyberPower PR3000ERTXL2U uninterruptible power supply (UPS) Line-Interactive 3 kVA 3000 W 8 AC outlet(s)
Brand: CyberPower
SKU: PR3000ERTXL2U

SKU: PR3000ERTXL2U

3 In Stock

Default

Warehouse	Stock	On Order	Lead Time/ETA*
Default	3	0

Local warehouse items can be delivered in 24h after the order is received. Central Warehouse can be delivered within 5 working days. Configuration units made to order take 1 or 3 weeks dependant on vendor spec.

Lead Time*: Order will be placed with the Vendor once we receive an order.

ETA*: An order has been placed with the Vendor. Date advised is the time required for the order to be delivered to our Warehouse.

CyberPower PR3000ERTXL2U, Line-Interactive, 3 kVA, 3000 W, Pure sine, 159 V, 288 V

Datasheets (Download)

Product manual (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
CyberPower

Warranty
2 Years

SKU
PR3000ERTXL2U

EAN
4712856277579

Battery

Battery recharge time
3 h

Battery technology
Sealed Lead Acid (VRLA)

Hot-swap battery
Yes

Number of batteries supported
4

Replacement battery cartridge
RBP0129

Typical backup time at full load
1.7 min

Typical backup time at half load
7.1 min

Bullet points

Certificates

Certification
CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2

Compliance certificates
RoHS

Design

Cable length
2.4 m

Display type
LCD

Form factor
Rackmount/Tower

Housing material
Metal

LED indicators
Error, Operation

Product colour
Black

Rack capacity
2U

Features

Audible alarm modes
Alarm when on battery, Low battery alarm, Overload alarm

Audible alarm(s)
Yes

Automatic Voltage Regulation (AVR)
Yes

EMI/RFI noise filtering
Yes

Input frequency
50/60 Hz

Input operation voltage (max)
288 V

Input operation voltage (min)
159 V

Management protocols
SNMP/HTTP

Maximum current
16 A

Number of input phases
1

Output frequency
50/60 Hz

Output operation voltage (max)
240 V

Output operation voltage (min)
220 V

Output power
3000 W

Output power capacity
3 kVA

Power factor
1

Power Factor Correction (PFC) type
Active

Power protection features
Overload, Short circuit

Response time
4 ms

Socket circuit breaker
Yes

Surge energy rating
2430 J

Surge protection
Yes

Transfer time (Line Mode to Battery Mode)
4 ms

UPS topology
Line-Interactive

Waveform
Pure sine

Web-based management
Yes

Logistics data

Country of origin
China

Harmonized System (HS) code
8504408590

Operational conditions

Non-operating altitude
0 - 15000 m

Operating altitude
0 - 3000 m

Operating relative humidity (H-H)
0 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
0 - 95%

Storage temperature (T-T)
-15 - 45 °C

Other features

Bypass
GreenPower UPS

Packaging data

Package depth
620 mm

Package height
275 mm

Package volume
40800 cm³

Package weight
41 kg

Package width
560 mm

Ports & interfaces

AC outlet types
C13 coupler, C19 coupler

AC outlets quantity
8 AC outlet(s)

Cabling technology
10/100/1000Base-T(X)

Emergency Power Off (EPO) connector
Yes

Ethernet LAN (RJ-45) ports
2

Power plug
C20 coupler

Serial interface
Yes

Serial interface type
RS-232

USB port
Yes

Sustainability

Sustainability certificates
ENERGY STAR

Weight & dimensions

Depth
500 mm

Height
86.5 mm

Weight
32.8 kg

Width
433 mm

Description

CyberPower PR3000ERTXL2U. UPS topology: Line-Interactive, Output power capacity: 3 kVA, Output power: 3000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 1.7 min, Typical backup time at half load: 7.1 min. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Compliance certificates: RoHS, Certification: CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2

Line-Interactive
3 kVA 3000 W
Waveform: Pure sine
8 AC outlet(s)
Sealed Lead Acid (VRLA)
Rackmount/Tower Black
Reliable Power Quality
Electricity Cost Savings
Device Protection Design
Automatic Voltage Regulation (AVR)
Real-time LCD Readout
