• Bullet points

• Point
• 16GB (2666MHz) DDR4-SDRAM (1 x 16) & 1000GB HDD
  iDRAC9 Express
  Intel Xeon E-2224G (8MB Cache, 3.5GHz)
  No OS

• Design

• Chassis type
• Tower

• Product colour
• Black

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x1 (Gen 3.x) slots
• 1

• PCI Express x16 (Gen 3.x) slots
• 1

• PCI Express x8 (Gen 3.x) slots
• 2

• Filters

• Machinecategory
• Server

• Graphics

• Maximum on-board graphics card memory
• 128 GB

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1200 MHz

• On-board graphics card ID
• 0x3E96

• On-board graphics card model
• Intel UHD Graphics P630

• On-board graphics card OpenGL version
• 4.5

• Memory

• Buffered memory type
• Unregistered (unbuffered)

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2666 MHz

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 1 x 16 GB

• Memory Slot Support
• 64 GB

• Memory slots
• 4x DIMM

• Network

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Non-operating altitude
• 0 - 12000 m

• Operating altitude
• 0 - 3048 m

• Operating relative humidity (H-H)
• 10 - 80%

• Operating temperature (T-T)
• 10 - 35 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Packaging content

• Cables included
• AC

• Performance

• Remote administration
• iDRAC9 Express

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 4

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 2

• Power supply
• 495 W

• Power supply input frequency
• 50 - 60 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Maximum internal memory supported by processor
• 128 GB

• Maximum number of PCI Express lanes
• 16

• Memory clock speeds supported by processor
• 2666 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• Processor
• E-2224G

• Processor boost frequency
• 4.7 GHz

• Processor cache
• 8 MB

• Processor codename
• Coffee Lake

• Processor family
• Intel Xeon E

• Processor frequency
• 3.5 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 37.5 x 37.5 mm

• Processor socket
• LGA 1151 (Socket H4)

• Processor threads
• 4

• Scalability
• 1S

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Tcase
• 69.3 °C

• Thermal Design Power (TDP)
• 71 W

• Thermal Monitoring Technologies
• Yes

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® InTru™ 3D Technology
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 191037

• Software

• Compatible operating systems
• - Microsoft Windows Server with Hyper-V - Red Hat Enterprise Linux - SUSE Linux Enterprise Server - VMware ESXi - Citrix XenServer - Ubuntu Server - Certify XenServer

• Operating system installed
• No

• Storage

• HDD capacity
• 1 TB

• HDD interface
• Serial ATA

• HDD size
• 3.5"

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 1

• Number of HDDs supported
• 8

• Optical drive type
• DVD-RW

• RAID support
• No

• Storage Capacity
• 1 TB

• Supported HDD sizes
• 3.5"

• Supported RAID controllers
• PERC H330

• Supported storage drive interfaces
• SAS, Serial ATA

• Weight & dimensions

• Depth
• 603 mm

• Height
• 430.3 mm

• Package depth
• 616 mm

• Package height
• 454 mm

• Package weight
• 29.6 kg

• Package width
• 789 mm

• Width
• 218 mm
