• Audio

• Audio chip
• Realtek ALC3286

• Audio system
• Dolby Atmos

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Number of microphones
• 2

• Battery

• Battery capacity
• 94 Wh

• Battery life (max)
• 14.6 h

• Battery technology
• Lithium Polymer (LiPo)

• Bullet points

• Point
• 2x 8GB SO-DIMM DDR4-2933 Non-ECC
  512GB SSD M.2 2280 PCIe NVMe Opal
  Intel Core i7-10750H (6C/12T, 2.6/5.0GHz, 12MB)
  NVIDIA Quadro T1000 4GB
  Windows 10 Pro 64

• Camera

• Front camera
• Yes

• Front camera HD type
• HD

• Front camera resolution
• 1280 x 720 pixels

• Infrared (IR) camera
• Yes

• Privacy camera
• Yes

• Privacy type
• Privacy shutter

• Certificates

• Certification
• MIL-STD-810G

• MIL-STD-810G compliant
• Yes

• Design

• Colour name
• Black

• Form factor
• Clamshell

• Product colour
• Black

• Product type
• Mobile workstation

• Display

• Anti-glare screen
• Yes

• Colour gamut
• 72%

• Contrast ratio (typical)
• 700:1

• Display brightness
• 300 cd/m²

• HD type
• Full HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Panel type
• IPS

• Screen Resolution
• 1920 x 1080 pixels

• Screen Size
• 43.9 cm (17.3")

• Touchscreen
• No

• Filters

• Machinecategory
• Mobile workstation

• Graphics

• Discrete GPU manufacturer
• NVIDIA

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 4 GB

• Discrete graphics card model
• NVIDIA Quadro T1000

• Discrete graphics memory type
• GDDR6

• On-board GPU manufacturer
• Intel

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1150 MHz

• On-board graphics card family
• Intel® UHD Graphics

• On-board graphics card ID
• 0x9BC4

• On-board graphics card model
• Intel® UHD Graphics

• On-board graphics card OpenGL version
• 4.5

• Keyboard

• Keyboard backlit
• Yes

• Keyboard language
• English

• Numeric keypad
• Yes

• Pointing device
• ThinkPad UltraNav

• Spill-resistant keyboard
• Yes

• Memory

• ECC
• No

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 3200 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 2 x 8 GB

• Memory Slot Support
• 128 GB

• Memory slots
• 4x SO-DIMM

• Network

• Antenna type
• 2x2

• Bluetooth
• Yes

• Bluetooth version
• 5.1

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Mobile network connection
• No

• Near Field Communication (NFC)
• No

• Top Wi-Fi standard
• Wi-Fi 6 (802.11ax)

• Wi-Fi standards
• 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

• WLAN controller manufacturer
• Intel

• WLAN controller model
• Intel Wi-Fi 6 AX201

• WWAN
• Not installed

• Operational conditions

• Maximum shipping altitude
• 3048 m

• Operating relative humidity (H-H)
• 8 - 95%

• Operating temperature (T-T)
• 5 - 35 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• 5 - 43 °C

• Ports & interfaces

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• HDMI version
• 2.0

• Thunderbolt 3 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
• 1

• USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
• 2

• USB Power Delivery
• Yes

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• USB Type-C DisplayPort Alternate Mode
• Yes

• Power

• AC adapter frequency
• 50/60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter power
• 170 W

• Processor

• Configurable TDP-down
• 35 W

• Maximum number of PCI Express lanes
• 16

• Motherboard chipset
• Intel WM490

• Number of Cores
• 6

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 3.0

• Processor
• i7-10750H

• Processor boost frequency
• 5 GHz

• Processor cache
• 12 MB

• Processor cache type
• Smart Cache

• Processor codename
• Comet Lake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2.6 GHz

• Processor generation
• 10th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• BGA 1440

• Processor threads
• 12

• System bus rate
• 8 GT/s

• Thermal Design Power (TDP)
• 45 W

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Flex Memory Access
• Yes

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• No

• Intel Trusted Execution Technology
• No

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Processor ARK ID
• 201837

• Processor package size
• 42 x 28 mm

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Fingerprint reader
• Yes

• Password protection
• Yes

• Password protection type
• HDD, Power on, Supervisor

• Smart card reader
• Yes

• Trusted Platform Module (TPM)
• Yes

• Trusted Platform Module (TPM) version
• 2.0

• Windows Hello
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Operating system language
• English

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD

• Number of SSDs installed
• 1

• NVMe
• Yes

• Optical drive type
• No

• SSD capacity
• 512 GB

• SSD form factor
• M.2

• SSD interface
• NVMe, PCI Express

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Total SSDs capacity
• 512 GB

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Gold, ENERGY STAR

• Weight & dimensions

• Depth
• 280.8 mm

• Height (front)
• 2.51 cm

• Height (rear)
• 3.33 cm

• Weight
• 3.5 kg

• Width
• 415.4 mm
