• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• Tower

• Number of 2.5" bays
• 4

• Number of 3.5" bays
• 4

• Number of 5.25" bays
• 1

• Placement supported
• Horizontal/Vertical

• Product colour
• Black

• Rack capacity
• 4U

• Expansion slots

• PCI Express x1 (Gen 3.x) slots
• 2

• PCI Express x16 (Gen 3.x) slots
• 1

• PCI Express x4 (Gen 3.x) slots
• 1

• PCI Express x8 (Gen 3.x) slots
• 1

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• On-board graphics card
• No

• On-board graphics card model
• Not available

• Memory

• ECC
• No

• Internal memory type
• DDR4-SDRAM

• Memory channels
• Quad-channel

• Memory clock speed
• 2666 MHz

• Memory Installed
• 16 GB

• Memory Slot Support
• 128 GB

• Memory slots
• 8x DIMM

• Non-ECC
• Yes

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• No

• Operational conditions

• Operating relative humidity (H-H)
• 5 - 85%

• Operating temperature (T-T)
• 10 - 35 °C

• Packaging content

• Display included
• No

• Manual
• Yes

• Performance

• Audio chip
• Realtek ALC671

• Audio system
• High Definition Audio

• BIOS type
• UEFI

• Motherboard chipset
• Intel® X299

• Password protection
• Yes

• Product type
• Workstation

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• SATA Ports
• 8

• Total number of SATA connectors
• 8

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 6

• Power

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Bus type
• DMI3

• ECC supported by processor
• No

• Maximum internal memory supported by processor
• 128 GB

• Maximum number of PCI Express lanes
• 44

• Memory clock speeds supported by processor
• 2666 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 10

• Number of processors installed
• 1

• PCI Express slots version
• 3.0

• Processor
• i9-7900X

• Processor boost frequency
• 4.3 GHz

• Processor cache
• 13.75 MB

• Processor cache type
• L3

• Processor codename
• Skylake

• Processor family
• Intel® Core™ i9 X-series

• Processor frequency
• 3.3 GHz

• Processor generation
• 7th gen Intel® Core™ i9

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 2066 (Socket R4)

• Processor threads
• 20

• Stepping
• U0

• System bus rate
• 8 GT/s

• Thermal Design Power (TDP)
• 140 W

• Tjunction
• 95 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Intel 64
• Yes

• Intel HD Graphics
• No

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 123613

• Processor code
• SR3L2

• Scalability
• 1S

• Supported instruction sets
• AVX 2.0, AVX-512, SSE4.1, SSE4.2

• Thermal solution specification
• PCG 2017X

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Storage

• Card reader integrated
• Yes

• Number of SSDs installed
• 1

• Number of storage drives installed
• 1

• Optical drive type
• DVD Super Multi

• RAID levels
• 0, 1, 5, 10

• RAID support
• Yes

• SSD capacity
• 256 GB

• SSD interface
• PCI Express

• Storage Capacity
• 256 GB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Silver, ENERGY STAR

• Weight & dimensions

• Depth
• 500 mm

• Height
• 433 mm

• Weight
• 18 kg

• Width
• 176 mm
