• Design

• Chassis type
• Rack (2U)

• Rack mounting
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• Filters

• Machinecategory
• Server

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory Installed
• 16 GB

• Memory slots
• 24

• Network

• Ethernet LAN
• Yes

• Operational conditions

• Non-operating altitude
• 0 - 12192 m

• Operating altitude
• 0 - 300 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating temperature (T-T)
• 5 - 35 °C

• Storage relative humidity (H-H)
• 5 - 93%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• Products per pallet
• 1 pc(s)

• Performance

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 6

• VGA (D-Sub) ports quantity
• 2

• Power

• Power supply input frequency
• 50 - 60 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Conflict-Free processor
• Yes

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Maximum internal memory supported by processor
• 1.54 TB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 59.7 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1600,1866 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Motherboard chipset
• Intel C610

• Number of Cores
• 6

• Number of processors installed
• 1

• Number of QPI links
• 2

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E5-2603V4

• Processor cache
• 15 MB

• Processor cache type
• Smart Cache

• Processor code
• SR2P0

• Processor codename
• Broadwell

• Processor family
• Intel® Xeon® E5 v4

• Processor frequency
• 1.7 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 45 x 52.5 mm

• Processor series
• Intel Xeon E5-2600 v4

• Processor socket
• LGA 2011-v3

• Processor threads
• 6

• Scalability
• 2S

• Stepping
• R0

• Supported instruction sets
• AVX 2.0

• System bus rate
• 6.4 GT/s

• Tcase
• 73 °C

• Thermal Design Power (TDP)
• 85 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• No

• Processor ARK ID
• 92993

• Storage

• HDD interface
• Serial ATA, Serial Attached SCSI (SAS)

• HDD size
• 2.5"

• Hot-Plug support
• Yes

• Hot-swap
• Yes

• RAID levels
• 0, 1, 5, 6, 10, 50, 60

• RAID support
• Yes

• Weight & dimensions

• Depth
• 766 mm

• Height
• 87 mm

• Width
• 482 mm
