• Certificates

• Certification
• CB, RoHS, WEEE

• Design

• Chassis type
• Tower

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 (Gen 3.x) slots
• 2

• PCI Express x4 (Gen 2.x) slots
• 1

• PCI Express x4 (Gen 3.x) slots
• 2

• PCI slots
• 1

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card
• Yes

• Memory

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 192 GB

• Memory slots
• 12

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 85%

• Operating temperature (T-T)
• 10 - 35 °C

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 3

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 6

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 1

• Number of redundant power supplies supported
• 2

• Power supply
• 450 W

• Power supply input frequency
• 47 - 63 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Conflict-Free processor
• No

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Maximum internal memory supported by processor
• 384 GB

• Maximum number of PCI Express lanes
• 24

• Maximum number of SMP processors
• 2

• Memory bandwidth supported by processor (max)
• 32 GB/s

• Memory channels supported by processor
• Triple

• Memory clock speeds supported by processor
• 800,1066,1333 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Motherboard chipset
• Intel® C602

• Number of Cores
• 4

• Number of processors installed
• 1

• Number of QPI links
• 1

• PCI Express configurations
• x4, x8, x16

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E5-2407V2

• Processor boost frequency
• 2.4 GHz

• Processor cache
• 10 MB

• Processor cache type
• Smart Cache

• Processor code
• SR1AK

• Processor codename
• Ivy Bridge EN

• Processor family
• Intel® Xeon® E5 V2 Family

• Processor frequency
• 2.4 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 45 x 42.5 mm

• Processor series
• Intel Xeon E5-2400 v2

• Processor socket
• LGA 1356 (Socket B2)

• Processor threads
• 4

• Scalability
• 2S

• Stepping
• S1

• Supported instruction sets
• AVX

• System bus rate
• 6.4 GT/s

• Tcase
• 76 °C

• Thermal Design Power (TDP)
• 80 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• No

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 75782

• Software

• Compatible operating systems
• Windows Server 2008, 2012/R2 Hyper-V Server Windows Web Server 2008 R2 Windows Small Business Server 2011 Windows Storage Server 2012/R2 SUSE Linux Enterprise Server 10+ Red Hat Enterprise Linux 5/6 Citrix XenServer

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA III, Serial Attached SCSI (SAS)

• HDD size
• 3.5"

• Number of HDDs supported
• 8

• Optical drive type
• DVD Super Multi

• RAID levels
• 0, 1, 10

• RAID support
• Yes

• Supported HDD sizes
• 3.5"

• Supported storage drive interfaces
• SAS, Serial ATA III

• Weight & dimensions

• Depth
• 651 mm

• Height
• 456 mm

• Width
• 177 mm
