• Design

• Chassis type
• Tower (4U)

• Redundant fans support
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 (Gen 3.x) slots
• 2

• PCI Express x8 (Gen 3.x) slots
• 5

• Filters

• Machinecategory
• Server

• Graphics

• Maximum graphics card memory
• 16 MB

• On-board graphics card
• Yes

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2133 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 512 GB

• Memory slots
• 16

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Operating relative humidity (H-H)
• 20 - 80%

• Operating temperature (T-T)
• 10 - 45 °C

• Storage relative humidity (H-H)
• 8 - 90%

• Storage temperature (T-T)
• -10 - 60 °C

• Other features

• Graphics card
• AST2400

• Graphics card family
• Aspeed

• Integrated BMC with IPMI
• Yes

• Intel® Virtualization Technology (Intel® VT)
• VT-d, VT-x

• Performance

• BIOS type
• UEFI

• Trusted Platform Module (TPM)
• No

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 3

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of redundant power supplies installed
• 1

• Number of redundant power supplies supported
• 2

• Power supply
• 750 W

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intelligent Platform Management Interface (IPMI) support
• Yes

• Maximum internal memory supported by processor
• 768 GB

• Maximum number of PCI Express lanes
• 40

• Maximum number of SMP processors
• 2

• Memory bandwidth supported by processor (max)
• 68 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1600,1866,2133 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Motherboard chipset
• Intel® C612

• Number of Cores
• 16

• Number of processors installed
• 1

• Number of QPI links
• 2

• Physical Address Extension (PAE)
• Yes

• Processor
• E5-2698V3

• Processor boost frequency
• 3.6 GHz

• Processor cache
• 40 MB

• Processor cache type
• L3

• Processor code
• SR1XE

• Processor family
• Intel Xeon E5 v3

• Processor frequency
• 2.3 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 52.5 mm

• Processor socket
• LGA 2011-v3

• Processor threads
• 32

• Scalability
• 2S

• Stepping
• C1

• Supported instruction sets
• AVX

• Supported processor sockets
• LGA 2011 (Socket R)

• System bus rate
• 9.6 GT/s

• Tcase
• 87.9 °C

• Thermal Design Power (TDP)
• 135 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 81060

• Software

• Compatible operating systems
• Microsoft Windows Server 2012 R2, 2012, 2008 R2 Windows Small Business Server 2011 Red Hat Enterprise Linux 6.5 SUSE Linux Enterprise Server 11 VMware vSphere (ESXi) 5.5 U2

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA III, Serial Attached SCSI (SAS)

• HDD size
• 3.5"

• Hot-swap
• Yes

• Maximum storage capacity
• 90 TB

• Number of HDDs supported
• 15

• Optical drive type
• DVD±RW

• RAID levels
• 0, 1, 5, 6, 10, 50, 60

• RAID support
• Yes

• Supported HDD sizes
• 3.5"

• Supported storage drive interfaces
• SAS, Serial ATA III

• Weight & dimensions

• Depth
• 686 mm

• Height
• 459 mm

• Width
• 251 mm
