Synology UC3400 NAS Rack (2U) Intel® Xeon® D D-1541 8 GB DDR4 96 TB HDD

Roll over image to zoom inClick to Open expanded view

Synology UC3400 NAS Rack (2U) Intel® Xeon® D D-1541 8 GB DDR4 96 TB HDD

Name: Synology UC3400 NAS Rack (2U) Intel® Xeon® D D-1541 8 GB DDR4 96 TB HDD
Brand: Synology
SKU: UC3400/96TB-HAS53

SKU: UC3400/96TB-HAS53

ETA 10 days

Synology UC3400, NAS, Rack (2U), Intel® Xeon® D, D-1541, 8 GB, DDR4

Add to compare

Product Properties

Manufacturer
Synology

Warranty
2 Years

Drive
With drives

SKU
UC3400/96TB-HAS53

EAN
5050914227241

Design

Chassis type
Rack (2U)

Cooling type
Active

Fan diameter
6 cm

Number of fans
2 fan(s)

Memory

Internal memory type
DDR4

Maximum RAM supported
64 GB

Memory Installed
8 GB

Network

Ethernet LAN
Yes

Ethernet LAN data rates
10,100,1000,10000 Mbit/s

Link aggregation
Yes

Supported network protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 35 °C

Storage temperature (T-T)
-20 - 60 °C

Other features

Compliance certificates
BSMI, CE, EAC, Federal Communications Commission (FCC), KC, RCM, UKCA, VCCI

Warranty period
5 year(s)

Performance

Access Control List (ACL)
Yes

Backup function
Yes

Reset button
Yes

Snapshot
Yes

Type
NAS

Ports & interfaces

Ethernet LAN (RJ-45) ports
3

USB port
No

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Number of power supply units
2

Power supply unit (PSU) capacity
500 W

Redundant power supply (RPS) support
Yes

Processor

Number of Cores
8

Processor
D-1541

Processor boost frequency
2.7 GHz

Processor cache
12 MB

Processor family
Intel® Xeon® D

Processor frequency
2.1 GHz

Processor manufacturer
Intel

Storage

Hot-swap drive bays
Yes

Installed storage drive type
HDD

Number of storage drives installed
12

Number of storage drives supported
12

RAID levels
0, 1, 5, 10, JBOD

RAID support
Yes

Storage drive capacity
8 TB

Storage drive interface
Serial Attached SCSI (SAS)

Storage drive sizes supported
2.5,3.5"

Storage drives installed
Yes

Supported file systems
BTRFS, ext4

Supported storage drive types
HDD & SSD

Total installed storage capacity
96 TB

Weight & dimensions

Depth
724 mm

Height
88 mm

Weight
19.7 kg

Width
482 mm

Description

Synology UC3400. Type: NAS. Chassis type: Rack (2U). Processor family: Intel® Xeon® D, Processor model: D-1541, Processor frequency: 2.1 GHz. Internal memory: 8 GB, Internal memory type: DDR4. Total installed storage capacity: 96 TB, Installed storage drive type: HDD

NAS Rack (2U)
Total installed storage capacity: 96 TB Number of storage drives supported: 12 HDD & SSD
Intel® Xeon® D D-1541 2.1 GHz
8 DDR4
Ethernet LAN
Cooling type: Active
500 W
