• Certificates

• Certification
• China CECP; GS Mark

• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• Midi Tower

• Number of 3.5" bays
• 4

• Number of 5.25" bays
• 1

• Placement supported
• Vertical

• Product colour
• Black

• Expansion slots

• Mini PCI Express slots
• 1

• PCI Express x16 (Gen 1.x) slots
• 1

• PCI Express x16 (Gen 2.x) slots
• 3

• Features

• Images Type Map
•

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card memory
• 3.07 TB

• Discrete graphics card model
• NVIDIA® Quadro® K4000

• On-board graphics card
• No

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory channels
• Quad-channel

• Memory clock speed
• 1866 MHz

• Memory Installed
• 32 GB

• Memory layout (slots x size)
• 4 x 8 GB

• Memory Slot Support
• 512 GB

• Memory slots
• 16x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wake-on-LAN ready
• Yes

• Wi-Fi
• No

• Other features

• Optical drives quantity
• 1

• Packaging content

• Cables included
• AC

• Display included
• No

• Keyboard included
• No

• Manual
• Yes

• Mouse included
• No

• Performance

• Audio system
• HD

• Motherboard chipset
• Intel® C602

• Password protection
• Yes

• Password protection type
• BIOS

• Product type
• Workstation

• Ports & interfaces

• DisplayPorts quantity
• 2

• DVI port
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• PS/2 ports quantity
• 2

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 6

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• Power

• Power supply
• 1300 W

• Processor

• Bus type
• QPI

• CPU multiplier (bus/core ratio)
• 28

• ECC supported by processor
• Yes

• FSB Parity
• No

• Maximum internal memory supported by processor
• 750 GB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 42.6 GB/s

• Memory clock speeds supported by processor
• 800,1066,1333,1600 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Number of Cores
• 6

• Number of processors installed
• 1

• Number of QPI links
• 2

• PCI Express configurations
• x4, x8, x16

• PCI Express slots version
• 3.0

• Processor
• E5-2630

• Processor boost frequency
• 2.8 GHz

• Processor cache
• 15 MB

• Processor cache type
• Smart Cache

• Processor codename
• Sandy Bridge EP

• Processor family
• Intel® Xeon® E5 Family

• Processor frequency
• 2.3 GHz

• Processor lithography
• 32 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Xeon E5-2600

• Processor socket
• LGA 2011 (Socket R)

• Processor threads
• 12

• Stepping
• C2

• System bus rate
• 7.2 GT/s

• Tcase
• 77.4 °C

• Thermal Design Power (TDP)
• 95 W

• Processor special features

• Conflict-Free processor
• No

• CPU configuration (max)
• 2

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 32 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Smart Connect Technology
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• No

• Intel® Rapid Start Technology
• No

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• No

• Intel® Smart Response Technology
• No

• Intel® Turbo Boost Technology
• 1.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Physical Address Extension (PAE)
• 46 bit

• Processor ARK ID
• 64593

• Processor package size
• 52.5 x 45.0 mm

• Scalability
• 2S

• Supported instruction sets
• AVX

• Thermal Monitoring Technologies
• Yes

• Software

• Drivers included
• Yes

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Trial software
• Microsoft Office

• Storage

• Card reader integrated
• No

• HDD capacity
• 1 TB

• HDD interface
• SATA

• HDD size
• 3.5"

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 1

• Optical drive type
• DVD±RW

• RAID levels
• 0, 1, 10

• RAID support
• Yes

• Storage Capacity
• 1 TB

• Storage type
• HDD

• Sustainability

• Sustainability certificates
• ENERGY STAR

• Weight & dimensions

• Depth
• 545 mm

• Height
• 438 mm

• Width
• 216 mm
