• Certificates

• Certification
• CE

• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• Rack-mounted chassis

• Number of 2.5" bays
• 4

• Number of 3.5" bays
• 5

• Number of 5.25" bays
• 1

• Placement supported
• Vertical

• Product colour
• Black, Red

• Rack capacity
• 4U

• Expansion slots

• PCI Express x1 (Gen 3.x) slots
• 2

• PCI Express x16 (Gen 3.x) slots
• 2

• PCI Express x4 (Gen 3.x) slots
• 2

• PCI Express x8 (Gen 3.x) slots
• 1

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 8 GB

• Discrete graphics card model
• NVIDIA® Quadro® P4000

• On-board graphics card
• No

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory channels
• Quad-channel

• Memory clock speed
• 2666 MHz

• Memory Installed
• 32 GB

• Memory layout (slots x size)
• 4 x 8 GB

• Memory Slot Support
• 256 GB

• Memory slots
• 8x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• No

• Operational conditions

• Operating relative humidity (H-H)
• 5 - 85%

• Operating temperature (T-T)
• 10 - 35 °C

• Other features

• Optical drives quantity
• 1

• Packaging content

• AC adapter included
• Yes

• Display included
• No

• Manual
• Yes

• Power cord included
• Yes

• Performance

• Audio chip
• Realtek ALC671

• Audio system
• High Definition Audio

• Motherboard chipset
• Intel® C422

• Password protection
• Yes

• Password protection type
• BIOS, Supervisor, User

• Product type
• Workstation

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• DC-in jack
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 2

• Line-out
• Yes

• Microphone in
• Yes

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 8

• Power

• Power supply
• 450 W

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Bus type
• QPI

• ECC supported by processor
• Yes

• Maximum internal memory supported by processor
• 512 GB

• Maximum number of PCI Express lanes
• 48

• Memory bandwidth supported by processor (max)
• 85.3 GB/s

• Memory clock speeds supported by processor
• 1600,1866,2133,2400,2666 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 1x4, 1x8

• PCI Express slots version
• 3.0

• Processor
• W-2125

• Processor boost frequency
• 4.5 GHz

• Processor cache
• 8.25 MB

• Processor codename
• Skylake

• Processor family
• Intel® Xeon®

• Processor frequency
• 4 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 2066 (Socket R4)

• Processor threads
• 8

• Stepping
• U0

• Tcase
• 64 °C

• Thermal Design Power (TDP)
• 120 W

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor ARK ID
• 126708

• Processor code
• SR3LM

• Processor package size
• 45 x 52.5 mm

• Scalability
• 1S

• Supported instruction sets
• AVX, AVX 2.0, AVX-512, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Optional operating system supplied
• Windows 10 Pro

• Pre-installed software
• Workplace Protect

• Trial software
• McAfee Multi Access Security, Microsoft Office

• Storage

• Card reader integrated
• Yes

• Number of SSDs installed
• 1

• Optical drive type
• DVD Super Multi

• RAID levels
• 0, 1, 5, 10

• RAID support
• Yes

• SSD capacity
• 512 GB

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• RoHS, ENERGY STAR

• Weight & dimensions

• Depth
• 500 mm

• Height
• 433 mm

• Weight
• 18 kg

• Width
• 176 mm
