• Enhanced Dual-socket compute plus high bandwidth DDR4 and Intel® Optane™ DC persistent memory - optimal for demanding enterprise and SME requirements. Intel® Optane™ DC persistent memory is an innovative memory technology which delivers a unique combination of affordable large capacity and non-volatile persistence. It revolutionizes the data center memory-storage hierarchy of the past and brings massive data sets closer to the CPU for faster time to insight. As such, the TX2550 M5 is capable of handling a range of diverse tasks
  Improve capability for Graphics intensive apps; get more from your display infrastructure

• Certificates

• Certification
• CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, VCCI, KN32, KN35, CCC, C-Tick

• Design

• Chassis type
• Tower

• Product colour
• Black

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 (Gen 3.x) slots
• 3

• PCI Express x8 (Gen 3.x) slots
• 5

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card model
• Not available

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2933 MHz

• Memory Installed
• 16 GB

• Memory Slot Support
• 1.5 TB

• Memory slots
• 8

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Fast Ethernet, Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 85%

• Operating temperature (T-T)
• 5 - 45 °C

• Packaging content

• Cables included
• AC

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 6

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of redundant power supplies installed
• 2

• Power supply
• 800 W

• Power supply input frequency
• 50/60 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Configurable TDP-down
• 85 W

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Maximum internal memory supported by processor
• 1.02 TB

• Maximum number of PCI Express lanes
• 48

• Memory clock speeds supported by processor
• 2400 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 8

• Number of processors installed
• 1

• Processor
• 4208

• Processor boost frequency
• 3.2 GHz

• Processor cache
• 11 MB

• Processor cache type
• L3

• Processor codename
• Cascade Lake

• Processor family
• Intel Xeon Silver

• Processor frequency
• 2.1 GHz

• Processor generation
• 2nd Generation Intel® Xeon® Scalable

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 76.0 x 56.5 mm

• Processor socket
• LGA 3647 (Socket P)

• Processor threads
• 16

• Scalability
• 2S

• Supported instruction sets
• AVX-512

• Tcase
• 78 °C

• Thermal Design Power (TDP)
• 85 W

• Processor special features

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 193390

• Software

• Compatible operating systems
• Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux

• Operating system installed
• No

• Storage

• Hot-Plug support
• Yes

• Number of HDDs supported
• 8

• Optical drive type
• DVD±RW

• RAID levels
• 0, 1, 5, 6, 10, 50, 60

• RAID support
• Yes

• Supported HDD sizes
• 2.5"

• Supported storage drive interfaces
• SAS, Serial ATA

• Weight & dimensions

• Depth
• 177 mm

• Height
• 456 mm

• Width
• 177 mm
