• Design

• Chassis type
• Tower (5U)

• Rack rails
• Yes

• Redundant fans support
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 (Gen 3.x) slots
• 4

• PCI Express x4 (Gen 2.x) slots
• 2

• PCI Express x8 (Gen 3.x) slots
• 2

• Filters

• Machinecategory
• Server

• Graphics

• Maximum graphics card memory
• 16 MB

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2400 MHz

• Memory Installed
• 32 GB

• Memory layout (slots x size)
• 2 x 16 GB

• Memory Slot Support
• 1.54 TB

• Memory slots
• 24x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Non-operating altitude
• 0 - 12000 m

• Operating altitude
• 0 - 3048 m

• Operating relative humidity (H-H)
• 10 - 80%

• Operating temperature (T-T)
• 10 - 35 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• Built-in display
• Yes

• Dell E-Value Code
• PET63005b

• Display
• LCD

• Graphics card
• G200

• Graphics card family
• Matrox

• Packaging content

• Cables included
• AC

• Performance

• Performance management
• IPMI 2.0, Dell OpenManage

• Remote administration
• iDRAC8 Express

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 5

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• VGA (D-Sub) ports quantity
• 2

• Power

• Number of redundant power supplies installed
• 1

• Power supply
• 750 W

• Power supply input frequency
• 50 - 60 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Compatible processor series
• Intel® Xeon®

• Conflict-Free processor
• Yes

• ECC supported by processor
• Yes

• Embedded options available
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Maximum internal memory supported by processor
• 1.54 TB

• Maximum number of PCI Express lanes
• 40

• Maximum number of SMP processors
• 2

• Memory bandwidth supported by processor (max)
• 68.3 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1600,1866,2133 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Motherboard chipset
• Intel C610

• Number of Cores
• 10

• Number of processors installed
• 1

• Number of QPI links
• 2

• PCI Express configurations
• 1x4, 1x8, 1x16

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E5-2640V4

• Processor boost frequency
• 3.4 GHz

• Processor cache
• 25 MB

• Processor cache type
• Smart Cache

• Processor codename
• Broadwell

• Processor family
• Intel® Xeon® E5 v4

• Processor frequency
• 2.4 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 52.5 x 51 mm

• Processor series
• Intel Xeon E5-2600 v4

• Processor socket
• LGA 2011-v3

• Processor threads
• 20

• Scalability
• 2S

• Stepping
• R0

• Supported instruction sets
• AVX 2.0

• Supported processor sockets
• LGA 2011-v3 (Socket R)

• System bus rate
• 8 GT/s

• Tcase
• 76 °C

• Thermal Design Power (TDP)
• 90 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Flex Memory Access
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 92984

• Software

• Compatible operating systems
• Microsoft Windows Server 2008 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R2 Microsoft Windows Server 2016 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux VMware ESX

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD

• HDD capacity
• 300 GB

• HDD interface
• Serial Attached SCSI (SAS)

• HDD size
• 2.5"

• HDD speed
• 10000 RPM

• Hot-Plug support
• Yes

• Hot-swap
• Yes

• Maximum storage capacity
• 19.2 TB

• Number of HDDs installed
• 1

• Number of HDDs supported
• 16

• Optical drive type
• DVD±RW

• RAID levels
• 0, 1, 5, 6, 10, 50, 60

• RAID support
• Yes

• Storage Capacity
• 300 GB

• Supported HDD sizes
• 2.5"

• Supported storage drive interfaces
• SAS, Serial ATA

• Weight & dimensions

• Depth
• 708.7 mm

• Height
• 443.5 mm

• Weight
• 37.6 kg

• Width
• 304.5 mm
