• Design

• Chassis type
• Rack (2U)

• Rack mounting
• Yes

• Redundant fans support
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 (Gen 3.x) slots
• 2

• PCI Express x8 (Gen 3.x) slots
• 4

• Filters

• Machinecategory
• Server

• Memory

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 2 x 4 GB

• Memory Slot Support
• 320 GB

• Memory slots
• 20x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Fast Ethernet, Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Intel® I350

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 6

• VGA (D-Sub) ports quantity
• 2

• Power

• Number of main power supplies
• 2

• Number of redundant power supplies installed
• 2

• Number of redundant power supplies supported
• 2

• Power supply
• 1600 W

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Conflict-Free processor
• No

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Maximum internal memory supported by processor
• 768 GB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 51.2 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 800,1066,1333,1600 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Motherboard chipset
• Intel® C602J

• Number of Cores
• 6

• Number of processors installed
• 1

• Number of QPI links
• 2

• PCI Express configurations
• x4, x8, x16

• Physical Address Extension (PAE)
• 46 bit

• Processor
• E5-2620V2

• Processor boost frequency
• 2.6 GHz

• Processor cache
• 15 MB

• Processor cache type
• Smart Cache

• Processor codename
• Ivy Bridge EP

• Processor family
• Intel® Xeon® E5 V2 Family

• Processor frequency
• 2.1 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 52.5 x 45 mm

• Processor series
• Intel Xeon E5-2600 v2

• Processor socket
• LGA 2011 (Socket R)

• Processor threads
• 12

• Scalability
• 2S

• Supported instruction sets
• AVX

• System bus rate
• 7.2 GT/s

• Tcase
• 71 °C

• Thermal Design Power (TDP)
• 80 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 75789

• Software

• Compatible operating systems
• Windows Server 2008 R2, Windows Server 2012, Windows Server 2008 RS SP1, Windows Small Business Server 2011, SUSE Linux Enterprise Server, Red Hat Enterprise Linux Server, VMware vSphere ESXi, Citrix XenServer

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA III, Serial Attached SCSI (SAS)

• HDD size
• 2.5"

• Number of HDDs supported
• 16

• Optical drive type
• DVD±RW

• RAID levels
• 0, 1, 5, 6, 10, 50, 60

• RAID support
• Yes

• Supported HDD sizes
• 2.5"

• Technical details

• Sustainability certificates
• ENERGY STAR

• Weight & dimensions

• Depth
• 734 mm

• Height
• 87 mm

• Weight
• 16 kg

• Width
• 482 mm
