• Design

• Chassis type
• Rack (1U)

• Expansion slots

• PCI Express slots version
• 2.0

• PCI Express x8 (Gen 3.x) slots
• 1

• Features

• Images Type Map
•

• Filters

• Machinecategory
• Server

• Graphics

• Number of displays supported (on-board graphics)
• 2

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 850 MHz

• On-board graphics card dynamic frequency (max)
• 1350 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card model
• Intel® HD Graphics P3000

• Memory

• Buffered memory type
• Unregistered (unbuffered)

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 2 x 4 GB

• Memory Slot Support
• 32 GB

• Memory slots
• 4x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• LAN controller
• Intel® I217-V

• Operational conditions

• Operating temperature (T-T)
• 10 - 35 °C

• Storage temperature (T-T)
• -10 - 60 °C

• Other features

• Graphics card
• HD Graphics P4600

• Graphics card family
• Intel

• Ports & interfaces

• DisplayPorts quantity
• 1

• Ethernet LAN (RJ-45) ports
• 3

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 4

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 1

• Power supply
• 300 W

• Redundant power supply (RPS) support
• No

• Processor

• Bus type
• DMI

• Conflict-Free processor
• No

• CPU multiplier (bus/core ratio)
• 31

• ECC supported by processor
• Yes

• Embedded options available
• Yes

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of PCI Express lanes
• 20

• Maximum number of SMP processors
• 1

• Memory bandwidth supported by processor (max)
• 21 GB/s

• Memory channels supported by processor
• Dual

• Memory clock speeds supported by processor
• 1066,1333 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Motherboard chipset
• Intel® C226

• Number of Cores
• 4

• Number of processors installed
• 1

• Processor
• E3-1225

• Processor boost frequency
• 3.4 GHz

• Processor cache
• 6 MB

• Processor cache type
• Smart Cache

• Processor code
• SR00G

• Processor codename
• Sandy Bridge

• Processor family
• Intel® Xeon® E3 Family

• Processor frequency
• 3.1 GHz

• Processor lithography
• 32 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 37.5 x 37.5 mm

• Processor series
• Intel Xeon E3-1200

• Processor socket
• LGA 1155 (Socket H2)

• Processor threads
• 4

• Stepping
• D2

• Supported instruction sets
• AVX, SSE4.1, SSE4.2

• System bus rate
• 5 GT/s

• Tcase
• 72.6 °C

• Thermal Design Power (TDP)
• 95 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 1

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Trusted Execution Technology
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 52270

• Software

• Compatible operating systems
• Windows Server 2012 R2 Windows Server 2012 Windows Server 2008 R2 Windows Small Business Server 2011 Red Hat Enterprise Linux 6.5 SUSE Linux Enterprise Server 11 VMware vSphere 5.5 (ESXi)

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA III

• HDD size
• 2.5"

• Number of HDDs supported
• 4

• Optical drive type
• No

• RAID levels
• 0, 1, 10

• RAID support
• Yes

• Supported HDD sizes
• 2.5"

• Weight & dimensions

• Depth
• 411.5 mm

• Height
• 43.4 mm

• Weight
• 7.35 kg

• Width
• 429.3 mm
