• Certificates

• Certification
• TÜV GS, CE, FCC Class B, cCSAus, WEEE, Microsoft Operating Systems (HCT / HCL entry / WHQL)

• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• mini PC

• Number of 2.5" bays
• 1

• Number of 5.25" bays
• 1

• Placement supported
• Horizontal/Vertical

• Product colour
• Black

• VESA mounting
• Yes

• Volume
• 2 L

• Filters

• Machinecategory
• Personal computer

• Graphics

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 1.7 GB

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 11.1

• On-board graphics card dynamic frequency (max)
• 1200 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x412

• On-board graphics card model
• Intel® HD Graphics 4600

• Memory

• Internal memory type
• DDR3-SDRAM

• Memory channels
• Dual-channel

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 2 x 4 GB

• Memory Slot Support
• 16 GB

• Memory slots
• 2x SO-DIMM

• Non-ECC
• Yes

• Network

• Bluetooth
• Yes

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 4 (802.11n)

• Wake-on-LAN ready
• Yes

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, 802.11g, Wi-Fi 4 (802.11n)

• Operational conditions

• Operating relative humidity (H-H)
• 5 - 85%

• Operating temperature (T-T)
• 10 - 35 °C

• Other features

• Optical drives quantity
• 1

• Panel mounting interface
• 100 x 100 mm

• Packaging content

• Display included
• No

• Manual
• Yes

• Performance

• Audio chip
• Realtek ALC671

• Audio output channels
• 5.1 channels

• BIOS type
• UEFI AMI

• Motherboard chipset
• Intel® Q87

• Password protection
• Yes

• Password protection type
• BIOS, HDD, Supervisor, User

• Product type
• Mini PC

• Ports & interfaces

• DisplayPorts quantity
• 1

• DVI port
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• SATA Ports
• 2

• Total number of SATA connectors
• 2

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• VGA (D-Sub) ports quantity
• 1

• Power

• Power supply
• 65 W

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Bus type
• DMI

• ECC supported by processor
• No

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of PCI Express lanes
• 16

• Memory bandwidth supported by processor (max)
• 25.6 GB/s

• Memory clock speeds supported by processor
• 1333,1600 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 3.0

• Processor
• i7-4785T

• Processor boost frequency
• 3.2 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor codename
• Haswell

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2.2 GHz

• Processor generation
• 4th gen Intel® Core™ i7

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i7-4700 Desktop series

• Processor socket
• LGA 1150 (Socket H3)

• Processor threads
• 8

• Stepping
• C0

• System bus rate
• 5 GT/s

• Tcase
• 66.35 °C

• Thermal Design Power (TDP)
• 35 W

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Enhanced Halt State
• Yes

• Intel FDI Technology
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 80814

• Processor code
• SR1QU

• Processor package size
• 37.5 x 37.5 mm

• Scalability
• 1S

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2013A

• Software

• Drivers included
• Yes

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Recovery operating system
• Windows 8.1 Pro

• Trial software
• Office 365

• Storage

• Card reader integrated
• Yes

• HDD capacity
• 500 GB

• HDD interface
• SATA III

• HDD size
• 2.5"

• Number of HDDs installed
• 1

• Number of storage drives installed
• 1

• Optical drive type
• DVD Super Multi

• Storage Capacity
• 500 GB

• Storage type
• HDD

• Sustainability

• Sustainability certificates
• Blue Angel, RoHS, EPEAT Gold, ENERGY STAR

• Weight & dimensions

• Depth
• 191 mm

• Height
• 58.7 mm

• Weight
• 1.6 kg

• Width
• 185 mm
