• Audio

• Audio system
• SRS Premium Sound PRO

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Battery

• Battery capacity
• 55 Wh

• Number of battery cells
• 6

• Camera

• Front camera
• Yes

• Certificates

• Wi-Fi certified
• Yes

• Design

• Country of origin
• China

• Form factor
• Clamshell

• Product colour
• Black, Silver

• Product type
• Laptop

• Display

• HD type
• HD+

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Screen Resolution
• 1600 x 900 pixels

• Screen Size
• 39.6 cm (15.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Notebook

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card model
• AMD Radeon HD 7570M

• Discrete graphics memory type
• GDDR5

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 650 MHz

• On-board graphics card dynamic frequency (max)
• 1300 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x166

• On-board graphics card model
• Intel® HD Graphics 4000

• Keyboard

• Numeric keypad
• Yes

• Pointing device
• Touchpad

• Spill-resistant keyboard
• Yes

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 4 GB

• Memory Slot Support
• 16 GB

• Memory slots
• 2x SO-DIMM

• Network

• 3G standards
• HSPA+

• Bluetooth
• Yes

• Bluetooth version
• 4.0

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Mobile network connection
• Yes

• Network Type
• 3G

• Top Wi-Fi standard
• Wi-Fi 4 (802.11n)

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, 802.11b, 802.11g

• Operational conditions

• Operating relative humidity (H-H)
• 20 - 80%

• Operating temperature (T-T)
• 10 - 35 °C

• Storage relative humidity (H-H)
• 10 - 90%

• Storage temperature (T-T)
• -15 - 60 °C

• Other features

• 3D
• No

• AC adapter included
• Yes

• Intel segment tagging
• Enterprise

• Maximum internal memory (64-bit)
• 16 GB

• Packaging content

• Cables included
• AC

• Manual
• Yes

• Quick start guide
• Yes

• Warranty card
• Yes

• Ports & interfaces

• CardBus PCMCIA slot type
• No

• Charging port type
• DC-in jack

• Combo headphone/mic port
• No

• DisplayPorts quantity
• 1

• Docking connector
• Yes

• DVI port
• No

• eSATA/USB 2.0 ports quantity
• 1

• Ethernet LAN (RJ-45) ports
• 1

• ExpressCard slot
• Yes

• Firewire (IEEE 1394) ports
• 1

• Headphone connectivity
• 3.5 mm

• Headphone outputs
• 1

• Microphone connectivity
• 3.5 mm

• Microphone in
• Yes

• S/PDIF out port
• No

• Serial ports quantity
• 1

• SmartCard slot
• No

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• VGA (D-Sub) ports quantity
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output voltage
• 19 V

• AC adapter power
• 90 W

• Power auto-sensing
• Yes

• Processor

• Bus type
• DMI

• CPU multiplier (bus/core ratio)
• 30

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum number of PCI Express lanes
• 16

• Motherboard chipset
• Intel® QM77 Express

• Number of Cores
• 2

• PCI Express configurations
• 1x8, 1x16, 2x4, 2x8

• PCI Express slots version
• 3.0

• Processor
• i7-3540M

• Processor boost frequency
• 3.7 GHz

• Processor cache
• 4 MB

• Processor cache type
• Smart Cache

• Processor codename
• Ivy Bridge

• Processor family
• Intel® Core™ i7

• Processor frequency
• 3 GHz

• Processor generation
• 3rd gen Intel® Core™ i7

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i7-3500 Mobile series

• Processor socket
• BGA 1023

• Processor threads
• 4

• Stepping
• L1

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 35 W

• Tjunction
• 105 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Integrated 4G WiMAX
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• No

• Intel® Smart Cache
• Yes

• Intel® Smart Response Technology
• No

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 71255

• Processor code
• SR0X8

• Processor package size
• 37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1023)

• Supported instruction sets
• AVX

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Software

• Drivers included
• Yes

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• MMC, SD

• HDD capacity
• 500 GB

• HDD interface
• SATA

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 1

• Optical drive type
• DVD Super Multi DL

• Storage Capacity
• 500 GB

• Storage type
• HDD

• Total HDDs capacity
• 500 GB

• Sustainability

• Sustainability certificates
• RoHS, ENERGY STAR

• Weight & dimensions

• Depth
• 251 mm

• Height
• 34 mm

• Weight
• 2.61 kg

• Width
• 374 mm
