• Audio

• Audio system
• HD

• Built-in microphone
• Yes

• Battery

• Battery capacity
• 3430 mAh
  38 Wh

• Battery technology
• Lithium Polymer (LiPo)

• Battery voltage
• 11.1 V

• Number of battery cells
• 3

• Camera

• Front camera
• Yes

• Design

• Form factor
• Clamshell

• Market positioning
• Educational

• Product colour
• Black

• Product type
• Laptop

• Display

• Display brightness
• 220 cd/m²

• Display surface
• Matt

• HD type
• Not supported

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Screen Resolution
• 1366 x 768 pixels

• Screen Size
• 29.5 cm (11.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Notebook

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 311 MHz

• On-board graphics card burst frequency
• 792 MHz

• On-board graphics card dynamic frequency (max)
• 792 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card model
• Intel® HD Graphics

• Keyboard

• Numeric keypad
• No

• Pointing device
• Touchpad

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR3L-SDRAM

• Memory clock speed
• 1600 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 2 GB

• Memory layout (slots x size)
• 1 x 2 GB

• Memory Slot Support
• 8 GB

• Memory slots
• 1x SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth Low Energy (BLE)
• Yes

• Bluetooth version
• 4.0

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• Yes

• Operational conditions

• Non-operating altitude
• -15.2 - 10668 m

• Non-operating shock
• 160 G

• Non-operating vibration
• 1.3 G

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating shock
• 110 G

• Operating temperature (T-T)
• 5 - 60 °C

• Operating vibration
• 0.66 G

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• AC adapter included
• Yes

• Intel segment tagging
• Education

• Intel® Virtualization Technology (Intel® VT)
• VT-x

• LightScribe
• No

• Maximum internal memory (64-bit)
• 8 GB

• Power adapter depth
• 10.6 cm

• Power adapter height
• 2.2 cm

• Power adapter width
• 6.6 cm

• Packaging content

• Manual
• Yes

• Power cord included
• Yes

• Ports & interfaces

• CardBus PCMCIA slot type
• No

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Docking connector
• No

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• ExpressCard slot
• No

• HDMI ports
• 1

• Microphone in
• No

• S/PDIF out port
• No

• SmartCard slot
• No

• Total number of SATA connectors
• 2

• USB 2.0 ports quantity
• 1

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 1

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output voltage
• 19.5 V

• AC adapter power
• 65 W

• Processor

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum number of PCI Express lanes
• 4

• Number of Cores
• 2

• PCI Express configurations
• 1x4

• PCI Express slots version
• 2.0

• Processor
• N2840

• Processor boost frequency
• 2.58 GHz

• Processor cache
• 1 MB

• Processor cache type
• L2

• Processor codename
• Bay Trail

• Processor family
• Intel® Celeron®

• Processor frequency
• 2.16 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 32-bit, 64-bit

• Processor series
• Intel Celeron Processor N2000 Series for Mobile

• Processor socket
• BGA 1170

• Processor threads
• 2

• Scenario Design Power (SDP)
• 4.5 W

• Stepping
• C0

• Thermal Design Power (TDP)
• 7.5 W

• Tjunction
• 100 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Smart Connect Technology
• Yes

• Intel Smart Connect Technology version
• 1.00

• Intel Trusted Execution Technology
• No

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• No

• Intel VT-x with Extended Page Tables (EPT)
• No

• Intel® Active Management Technology (Intel® AMT)
• No

• Intel® AES New Instructions (Intel® AES-NI)
• No

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® High Definition Audio (Intel® HD Audio)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® Matrix Storage Technology (Intel® MST)
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• Yes

• Intel® Rapid Start Technology
• No

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• No

• Intel® Smart Response Technology
• No

• Intel® Turbo Boost Technology
• No

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 82103

• Processor code
• SR1YJ

• Processor package size
• 25 x 27 mm

• Thermal Monitoring Technologies
• No

• Security

• Cable lock slot
• Yes

• Password protection
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD

• HDD capacity
• 250 GB

• HDD interface
• SATA

• HDD size
• 2.5"

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 1

• Optical drive type
• No

• Storage Capacity
• 250 GB

• Storage type
• HDD

• Sustainability

• Sustainability certificates
• RoHS, ENERGY STAR

• Weight & dimensions

• Depth
• 212 mm

• Height
• 22.9 mm

• Weight
• 1.35 kg

• Width
• 301 mm
