• Certificates

• Certification
• CB, RoHS, WEEE, GS, CE, CSAc/US, ULc/US, FCC, VCCI, GOST, KC, CCC, BSMI

• Design

• Chassis type
• Rack (1U)

• Rack mounting
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x4 (Gen 2.x) slots
• 1

• PCI Express x8 (Gen 3.x) slots
• 2

• Graphics

• On-board graphics card
• No

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 32 GB

• Memory slots
• 4

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Intel I210

• Supported protocols
• TCP/IP

• Wake-on-LAN ready
• Yes

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 85%

• Operating temperature (T-T)
• 10 - 35 °C

• Other features

• Intel® Virtualization Technology (Intel® VT)
• VT-d, VT-x

• Performance

• Noise level
• 34 dB

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• RS-232 ports
• 1

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 4

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 1

• Number of redundant power supplies supported
• 2

• Power consumption (typical)
• 197 W

• Power supply
• 450 W

• Power supply input frequency
• 50 - 60 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• DMI

• Conflict-Free processor
• No

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of PCI Express lanes
• 16

• Maximum number of SMP processors
• 1

• Memory bandwidth supported by processor (max)
• 25.6 GB/s

• Memory channels supported by processor
• Dual

• Memory clock speeds supported by processor
• 1333,1600 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Motherboard chipset
• Intel® C226

• Number of Cores
• 4

• Number of processors installed
• 1

• Number of QPI links
• 1

• PCI Express configurations
• 1x8, 1x16, 2x4, 2x8

• Processor
• E3-1220V3

• Processor boost frequency
• 3.5 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor codename
• Haswell

• Processor family
• Intel® Xeon® E3 V3 Family

• Processor frequency
• 3.1 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 37.5 x 37.5 mm

• Processor series
• Intel Xeon E3-1200 v3

• Processor socket
• LGA 1150 (Socket H3)

• Processor threads
• 4

• Scalability
• 1S

• Stepping
• C0

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 80 W

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2013D

• Processor special features

• CPU configuration (max)
• 1

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• No

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 75052

• Software

• Compatible operating systems
• Hyper-V Server R2 2012 Windows Server 2012 R2 Datacenter Windows Server 2012 R2 Standard Windows Server 2012 R2 Essentials Windows Server 2012 R2 Foundation Windows Storage Server 2012 R2 Standard Hyper-V Server 2012 Windows Server 2012 Datacenter Windows Server 2012 Standard Windows Server 2012 Essentials Windows Server 2012 Foundation Windows Storage Server 2012 Standard Hyper-V Server 2008 R2 Windows Server 2008 R2 Datacenter Windows Server 2008 R2 Enterprise Windows Server 2008 R2 Standard Windows Server 2008 R2 Foundation Windows Web Server 2008 R2 Windows Small Business Server 2011 Premium Add-On Windows Small Business Server Standard 2011 VMware vSphere 5.5 Embedded VMware vSphere 5.5 SUSE Linux Enterprise Server 11 Red Hat Enterprise Linux 6 Red Hat Enterprise Linux 5

• Operating system installed
• No

• Storage

• Hot-Plug support
• Yes

• Number of HDDs supported
• 4

• Optical drive type
• DVD Super Multi

• RAID levels
• 0, 1

• RAID support
• Yes

• Supported HDD sizes
• 2.5,3.5"

• Supported storage drive interfaces
• SAS, Serial ATA

• Weight & dimensions

• Depth
• 435.4 mm

• Height
• 42.8 mm

• Weight
• 13 kg

• Width
• 482.6 mm
