Synology DiskStation DS1823xs+ NAS Tower Ryzen Embedded V1780B 8 GB DDR4 128 TB HDD DiskStation Manager Black

Roll over image to zoom inClick to Open expanded view

Synology DiskStation DS1823xs+ NAS Tower Ryzen Embedded V1780B 8 GB DDR4 128 TB HDD DiskStation Manager Black

Name: Synology DiskStation DS1823xs+ NAS Tower Ryzen Embedded V1780B 8 GB DDR4 128 TB HDD DiskStation Manager Black
Brand: Synology
SKU: DS1823XS+/128TB-HAT33

SKU: DS1823XS+/128TB-HAT33

2 In Stock

2

Default

Warehouse	Stock	On Order	Lead Time/ETA*
Default	2	0

Local warehouse items can be delivered in 24h after the order is received. Central Warehouse can be delivered within 5 working days. Configuration units made to order take 1 or 3 weeks dependant on vendor spec.

Lead Time*: Order will be placed with the Vendor once we receive an order.

ETA*: An order has been placed with the Vendor. Date advised is the time required for the order to be delivered to our Warehouse.

Synology DiskStation DS1823xs+, NAS, Tower, Ryzen Embedded, V1780B, 8 GB, DDR4

Product manual (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Synology

Warranty
3 Years

SKU
DS1823XS+/128TB-HAT33

EAN
5050914243050

Bullet points

Design

Built-in display
No

Built-in speaker(s)
No

Cable lock slot
Yes

Cable lock slot type
Kensington

Chassis type
Tower

Cooling type
Active

Drive bay locking
Yes

Fan diameter
12 cm

LED indicators
Yes

Number of fans
2 fan(s)

Product colour
Black

Memory

ECC
Yes

Internal memory type
DDR4

Maximum RAM supported
32 GB

Memory form factor
SO-DIMM

Memory Installed
8 GB

Memory slots
2

Network

Copper ethernet cabling technology
10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T

Ethernet LAN
Yes

Ethernet LAN data rate supported (max)
10000 Mbit/s

Ethernet LAN data rates
10,100,1000,10000 Mbit/s

iSCSI support
Yes

Link aggregation
Yes

Supported network protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 60 °C

Other features

Compliance certificates
BSMI, CCC, CE, EAC, Federal Communications Commission (FCC), KC, RCM, RoHS, VCCI

Packaging content

Cables included
AC, LAN (RJ-45)

Power cables quantity
1

Performance

Access Control List (ACL)
Yes

Backup features
Cloud, iSCSI LUN

Backup function
Yes

Browser supported
Chrome, Firefox, Edge, Safari

Built-in FTP server
Yes

Card reader integrated
No

Device class
Small & Medium Business

Hot spare
Yes

Management protocols
SNMP

Multilingual support
Yes

Noise level
23.6 dB

Number of users
16000 user(s)

On/off switch
Yes

Reset button
Yes

Security algorithms
AES, HTTPS, SSH, SSL/TLS

Snapshot
Yes

System log
Yes

Type
NAS

Ports & interfaces

Concurrent connections
2000

eSATA ports quantity
2

Ethernet LAN (RJ-45) ports
4

PCI Express x8 (Gen 3.x) slots
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3

USB port
Yes

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Number of power supply units
1

Power consumption (HDD standby)
28.37 W

Power consumption (typical)
87.93 W

Power supply location
Built-in

Power supply unit (PSU) capacity
250 W

Redundant power supply (RPS) support
No

Processor

Number of Cores
4

Number of processors supported
1

Processor
V1780B

Processor boost frequency
3.6 GHz

Processor family
Ryzen Embedded

Processor frequency
3.35 GHz

Processor generation
AMD Ryzen Embedded V1000 Series

Processor manufacturer
AMD

Processor threads
8

Software

Operating system installed
DiskStation Manager

Operating system version
7.1.1

Server operating systems supported
Windows Server 2019

Storage

Hot-swap drive bays
Yes

Installed storage drive type
HDD

Number of M.2 (M & B) slots
2

Number of storage drives supported
8

Online RAID expansion
Yes

Online RAID migration
Yes

RAID levels
0, 1, 5, 6, 10, F1, JBOD

RAID support
Yes

Storage drive interface
Serial ATA III

Storage drive sizes supported
2.5,3.5,M.2

Storage drives installed
Yes

Supported file systems
BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4

Supported storage drive interfaces
Serial ATA III

Supported storage drive types
HDD & SSD

Total installed storage capacity
128 TB

Weight & dimensions

Depth
243 mm

Height
166 mm

Width
343 mm

Description

Synology DiskStation DS1823xs+. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: Ryzen Embedded, Processor model: V1780B, Processor frequency: 3.35 GHz. Internal memory: 8 GB, Internal memory type: DDR4. Total installed storage capacity: 128 TB, Installed storage drive type: HDD. Operating system installed: DiskStation Manager

Small & Medium Business NAS Tower Black
DiskStation Manager 7.1.1
Total installed storage capacity: 128 TB Number of storage drives supported: 8 HDD & SSD Serial ATA III
Ryzen Embedded V1780B 3.35 GHz
8 DDR4 Memory slots: 2 SO-DIMM ECC
Ethernet LAN 10000 iSCSI support Wake-on-LAN ready
Cooling type: Active
Backup features: Cloud, iSCSI LUN 250 W
Over 3,100/2,600 MB/s seq. read/write, built-in 10GbE, and up to 160 TB raw storage before expansion
Add up to 10 extra drive bays, 25GbE or Fibre Channel, and SSD cache volumes when needed
Back up 300 endpoints, manage 75 IP cameras, or safely sync and share files between devices and sites
