• Design

• Chassis type
• Blade

• Expansion slots

• PCI Express slots version
• 3.0

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card
• Yes

• On-board graphics card model
• Matrox G200eh

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2400 MHz

• Memory Installed
• 64 GB

• Memory layout (slots x size)
• 4 x 16 GB

• Memory Slot Support
• 4.1 TB

• Memory slots
• 32x DIMM

• Network

• Ethernet interface type
• 10 Gigabit Ethernet

• Ethernet LAN
• Yes

• Performance

• Trusted Platform Module (TPM)
• Yes

• Trusted Platform Module (TPM) version
• 1.2

• Power

• Redundant power supply (RPS) support
• No

• Processor

• Bus type
• QPI

• Conflict-Free processor
• Yes

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Maximum internal memory supported by processor
• 1.54 TB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 68 GB/s

• Memory channels supported by processor
• Quad

• Memory types supported by processor
• DDR4-SDRAM

• Motherboard chipset
• Intel C610

• Number of Cores
• 10

• Number of processors installed
• 2

• Number of QPI links
• 2

• PCI Express configurations
• 1x16, 1x4, 1x8

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E5-4610V4

• Processor boost frequency
• 1.8 GHz

• Processor cache
• 25 MB

• Processor cache type
• Smart Cache

• Processor code
• SR2SE

• Processor codename
• Broadwell

• Processor family
• Intel® Xeon® E5 v4

• Processor frequency
• 1.8 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 45 x 52.5 mm

• Processor socket
• LGA 2011-v3

• Processor threads
• 20

• Scalability
• 4S

• Stepping
• M0

• Supported instruction sets
• AVX 2.0

• System bus rate
• 6.4 GT/s

• Tcase
• 79 °C

• Thermal Design Power (TDP)
• 105 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 4

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• No

• Intel Instruction Replay Technology
• No

• Intel Instruction Replay Technology version
• 0.00

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• No

• Processor ARK ID
• 93812

• Software

• Compatible operating systems
• Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware

• Operating system installed
• No

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• MicroSDHC

• HDD interface
• Serial ATA, Serial Attached SCSI (SAS)

• HDD size
• 2.5"

• Hot-Plug support
• Yes

• Maximum storage capacity
• 61.2 TB

• Number of HDDs supported
• 4

• Optical drive type
• No

• RAID levels
• 0, 1, 5

• RAID support
• Yes

• Supported storage drive interfaces
• SAS, Serial ATA

• Weight & dimensions

• Depth
• 516.7 mm

• Height
• 366.3 mm

• Weight
• 12.3 kg

• Width
• 56.5 mm
