• Audio

• Audio system
• Waves MaxxAudio Pro

• Built-in microphone
• Yes

• Built-in speaker(s)
• Yes

• RMS rated power
• 2 W

• Camera

• Built-in camera
• Yes

• Camera resolution
• 1280 x 720 pixels

• Design

• Product colour
• Black

• Display

• Display brightness
• 350 cd/m²

• Full HD
• Yes

• HD type
• Full HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Panel type
• IPS

• Screen Resolution
• 1920 x 1080 pixels

• Screen Size
• 46.7 cm (18.4")

• Touch technology
• Multi-touch

• Touchscreen
• Yes

• Filters

• Machinecategory
• Personal computer

• Graphics

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card dynamic frequency (max)
• 1200 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x166

• On-board graphics card model
• Intel® HD Graphics 4000

• Memory

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 8 GB

• Memory slots
• 1

• Memory slots type
• SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth version
• 4.0

• Ethernet LAN
• No

• Top Wi-Fi standard
• Wi-Fi 4 (802.11n)

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, 802.11b, 802.11g

• Operational conditions

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating temperature (T-T)
• 0 - 35 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• AC adapter output current
• 3.34 A

• Autonomy mode
• Yes

• Battery capacity
• 69 Wh

• Number of battery cells
• 8

• Power auto-sensing
• Yes

• Storage drive interface
• Serial ATA

• Packaging content

• Keyboard included
• No

• Mouse included
• No

• Performance

• Motherboard chipset
• Intel® H77 Express

• Product type
• All-in-One PC

• Ports & interfaces

• Combo headphone/mic port
• Yes

• Headphone outputs
• 1

• Microphone in
• No

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• Power

• AC adapter frequency
• 50/60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output voltage
• 19.5 V

• AC adapter power
• 65 W

• Processor

• 64-bit computing
• Yes

• Bus type
• DMI

• Conflict-Free processor
• Yes

• CPU multiplier (bus/core ratio)
• 20

• ECC supported by processor
• No

• FSB Parity
• No

• Integrated 4G WiMAX
• Yes

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of PCI Express lanes
• 16

• Memory bandwidth supported by processor (max)
• 25.6 GB/s

• Memory channels supported by processor
• Dual

• Memory clock speeds supported by processor
• 1333,1600 MHz

• Memory types supported by processor
• DDR3-SDRAM, DDR3L-SDRAM

• Number of Cores
• 2

• PCI Express configurations
• 1x8, 1x16, 2x4, 2x8

• PCI Express slots version
• 2.0

• Processor
• i7-3537U

• Processor boost frequency
• 3.1 GHz

• Processor cache
• 4 MB

• Processor cache type
• Smart Cache

• Processor code
• SR0XG

• Processor codename
• Ivy Bridge

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2 GHz

• Processor generation
• 3rd gen Intel® Core™ i7

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i7-3500 Mobile series

• Processor socket
• BGA 1023

• Processor threads
• 4

• Stepping
• L1

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 17 W

• Tjunction
• 105 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• No

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 72054

• Processor package size
• 31 x 24 (BGA1023)

• Supported instruction sets
• AVX

• Thermal Monitoring Technologies
• Yes

• Software

• Bundled software
• McAfee 1YR

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 8.1 Pro

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• Memory Stick (MS), MMC, MS PRO, SD, SDHC, SDXC, xD

• HDD interface
• SATA

• HDD speed
• 5400 RPM

• Number of SSDs installed
• 1

• Number of storage drives installed
• 2

• Optical drive type
• No

• SSD capacity
• 32 GB

• SSD interface
• mSATA

• Storage Capacity
• 532 GB

• Storage type
• HDD+SSD

• Sustainability

• Sustainability certificates
• EPEAT Gold, ENERGY STAR

• Weight & dimensions

• Depth (with stand)
• 283.7 mm

• Height (with stand)
• 17.7 mm

• Weight (with stand)
• 2.2 kg

• Width (with stand)
• 463.6 mm
