• Audio

• Audio system
• Realtek ALC3233

• Built-in microphone
• Yes

• Battery

• Battery capacity
• 45 Wh

• Battery life (max)
• 9.5 h

• Battery recharge time
• 2 h

• Battery technology
• Lithium Polymer (LiPo)

• Number of battery cells
• 4

• Camera

• Front camera
• Yes

• Certificates

• Certification
• CE, CB, WEEE, Microsoft Operating Systems (HCT / HCL entry / WHQL)

• Design

• Form factor
• Clamshell

• Housing material
• Aluminium, Magnesium

• Product colour
• Black, Silver

• Product type
• Ultrabook

• Display

• Contrast ratio (typical)
• 400:1

• Display brightness
• 250 cd/m²

• Display surface
• Matt

• HD type
• HD+

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Screen Resolution
• 1600 x 900 pixels

• Screen Size
• 35.6 cm (14")

• Touchscreen
• No

• Filters

• Machinecategory
• Ultrabook

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• Graphics card Open GL support
• Yes

• Maximum on-board graphics card memory
• 16 GB

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 300 MHz

• On-board graphics card DirectX version
• 11.2

• On-board graphics card dynamic frequency (max)
• 900 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x1616

• On-board graphics card model
• Intel® HD Graphics 5500

• On-board graphics card OpenGL version
• 4.3

• Keyboard

• Full-size keyboard
• Yes

• Keyboard number of keys
• 85

• Numeric keypad
• No

• Pointing device
• Touchpad

• Spill-resistant keyboard
• Yes

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR3L-SDRAM

• Memory clock speed
• 1600 MHz

• Memory form factor
• On-board

• Memory Installed
• 4 GB

• Memory layout (slots x size)
• 1 x 4 GB

• Memory Slot Support
• 12 GB

• Memory slots
• 1x SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth version
• 4.0

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• Wi-Fi 5 (802.11ac)

• Operational conditions

• Operating relative humidity (H-H)
• 20 - 85%

• Operating temperature (T-T)
• 5 - 35 °C

• Other features

• AC adapter included
• Yes

• SIM card support
• Yes

• Packaging content

• Manual
• Yes

• Warranty card
• Yes

• Ports & interfaces

• Charging port type
• DC-in jack

• DisplayPorts quantity
• 1

• Docking connector
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• ExpressCard slot
• Yes

• Headphone outputs
• 1

• Line-in
• Yes

• Microphone in
• Yes

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• VGA (D-Sub) ports quantity
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output voltage
• 19 V

• Processor

• Bus type
• DMI2

• Configurable TDP-down
• 10 W

• Configurable TDP-down frequency
• 0.6 GHz

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum number of PCI Express lanes
• 12

• Number of Cores
• 2

• PCI Express configurations
• 2x4, 4x1

• PCI Express slots version
• 2.0

• Processor
• i3-5010U

• Processor cache
• 3 MB

• Processor cache type
• L3

• Processor codename
• Broadwell

• Processor family
• Intel® Core™ i3

• Processor frequency
• 2.1 GHz

• Processor generation
• 5th gen Intel® Core™ i3

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 32-bit, 64-bit

• Processor series
• Intel Core i3-5000 Mobile series

• Processor socket
• BGA 1168

• Processor threads
• 4

• Stepping
• F0

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 15 W

• Tjunction
• 105 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• Yes

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 14 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel HD Graphics
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Smart Response Technology version
• 1.00

• Intel Stable Image Platform Program (SIPP)
• No

• Intel Stable Image Platform Program (SIPP) version
• 0.00

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Built-in Visuals Technology
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• Yes

• Intel® Smart Cache
• No

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• No

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 84697

• Processor code
• SR23Z

• Processor package size
• 40 x 24x 1.3 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Fingerprint reader
• Yes

• Password protection
• Yes

• Password protection type
• BIOS, HDD, Supervisor, User

• Trusted Platform Module (TPM)
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Recovery operating system
• Windows 10 Pro

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD, SDHC, SDXC

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 128 GB

• SSD form factor
• 2.5"

• SSD interface
• SATA III

• Storage Capacity
• 128 GB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Gold, ENERGY STAR

• Weight & dimensions

• Depth
• 234 mm

• Height
• 19 mm

• Weight
• 1.5 kg

• Width
• 332.6 mm
