• Audio

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Speaker power
• 2 W

• Battery

• Battery capacity
• 35 Wh

• Battery technology
• Lithium Polymer (LiPo)

• Number of battery cells
• 4

• Camera

• Front camera
• Yes

• Design

• Form factor
• Convertible (Folder)

• Product colour
• Black

• Product type
• Hybrid (2-in-1)

• Display

• HD type
• HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Panel type
• IPS

• Screen Resolution
• 1366 x 768 pixels

• Screen Size
• 29.5 cm (11.6")

• Touch technology
• Multi-touch

• Touchscreen
• Yes

• Touchscreen type
• Capacitive

• Filters

• Machinecategory
• Notebook

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 16 GB

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 300 MHz

• On-board graphics card DirectX version
• 11.2/12

• On-board graphics card dynamic frequency (max)
• 800 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x161E

• On-board graphics card model
• Intel® HD Graphics 5300

• On-board graphics card OpenGL version
• 4.3

• Keyboard

• Numeric keypad
• No

• Pointing device
• ThinkPad UltraNav

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR3L-SDRAM

• Memory clock speed
• 1600 MHz

• Memory form factor
• On-board

• Memory Installed
• 4 GB

• Memory Slot Support
• 4 GB

• Network

• Bluetooth
• Yes

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

• Other features

• AC adapter included
• Yes

• Intel segment tagging
• Education, Industrial

• Ports & interfaces

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Docking connector
• No

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• Microphone in
• No

• USB 2.0 ports quantity
• 1

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 1

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• Power

• AC adapter power
• 45 W

• Processor

• Configurable TDP-down
• 3.5 W

• Configurable TDP-down frequency
• 0.6 GHz

• Configurable TDP-up
• 6 W

• Configurable TDP-up frequency
• 1 GHz

• ECC supported by processor
• No

• Maximum number of PCI Express lanes
• 12

• Number of Cores
• 2

• PCI Express configurations
• x1 (6), x2 (4), x4 (3)

• PCI Express slots version
• 2.0

• Processor
• M-5Y10c

• Processor boost frequency
• 2 GHz

• Processor cache
• 4 MB

• Processor cache type
• L3

• Processor codename
• Broadwell

• Processor family
• Intel® Core™ M

• Processor frequency
• 0.8 GHz

• Processor generation
• Intel® Core™ m-5xxx

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 32-bit, 64-bit

• Processor series
• Intel Core M-5Y Mobile series

• Processor socket
• BGA 1234

• Processor threads
• 4

• Scenario Design Power (SDP)
• 3.5 W

• Stepping
• F0

• Thermal Design Power (TDP)
• 4.5 W

• Tjunction
• 95 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 14 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Smart Response Technology version
• 1.00

• Intel Stable Image Platform Program (SIPP)
• No

• Intel Stable Image Platform Program (SIPP) version
• 0.00

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• Yes

• Intel® Smart Cache
• Yes

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 85234

• Processor code
• SR23C

• Processor package size
• 30 x 16.5 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• MMC, SD, SDHC, SDXC

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 192 GB

• Storage Capacity
• 192 GB

• Storage type
• SSD

• Weight & dimensions

• Depth
• 216 mm

• Height
• 25.3 mm

• Weight
• 1.59 kg

• Width
• 300 mm
